本文實例為大家分享了利用python和OpenCV實現圖像拼接，供大家參考，具體內容如下

python+OpenCV實現image stitching

在最新的OpenCV官方文檔中可以找到C++版本的Stitcher類的說明, 但是python版本的還沒有及時更新, 本篇對python版本的實現做一個簡單的介紹.

由于官方文檔中還沒有python版本的Stitcher類的說明, 因此只能自己去GitHub源碼上找, 以下是stitching的樣例:

from __future__ import print_functionimport cv2 as cvimport numpy as npimport argparseimport sysmodes = (cv.Stitcher_PANORAMA, cv.Stitcher_SCANS)parser = argparse.ArgumentParser(description=’Stitching sample.’)parser.add_argument(’--mode’, type = int, choices = modes, default = cv.Stitcher_PANORAMA, help = ’Determines configuration of stitcher. The default is `PANORAMA` (%d), ’ ’mode suitable for creating photo panoramas. Option `SCANS` (%d) is suitable ’ ’for stitching materials under affine transformation, such as scans.’ % modes)parser.add_argument(’--output’, default = ’result.jpg’, help = ’Resulting image. The default is `result.jpg`.’)parser.add_argument(’img’, nargs=’+’, help = ’input images’)args = parser.parse_args()# read input imagesimgs = []for img_name in args.img: img = cv.imread(img_name) if img is None: print('can’t read image ' + img_name) sys.exit(-1) imgs.append(img)stitcher = cv.Stitcher.create(args.mode)status, pano = stitcher.stitch(imgs)if status != cv.Stitcher_OK: print('Can’t stitch images, error code = %d' % status) sys.exit(-1)cv.imwrite(args.output, pano);print('stitching completed successfully. %s saved!' % args.output)

上面寫了一大堆, 然鵝, 直接拿來用的話, 用下面的代碼可以了, 簡單粗暴

import numpy as npimport cv2from cv2 import Stitcherif __name__ == '__main__': img1 = cv2.imread(’1.jpg’) img2 = cv2.imread(’2.jpg’) stitcher = cv2.createStitcher(False) #stitcher = cv2.Stitcher.create(cv2.Stitcher_PANORAMA), 根據不同的OpenCV版本來調用 (_result, pano) = stitcher.stitch((img1, img2)) cv2.imshow(’pano’,pano) cv2.waitKey(0)

效果如下：

原圖：

拼接后的圖像：

以上就是本文的全部?jī)?nèi)容，希望對大家的學習有所幫助，也希望大家多多支持好吧啦網。
